SC Connector 1550nm 68 DBuV WDM CATV Optical Node
| Place of Origin | Shanghai China |
|---|---|
| Brand Name | Yogel or OEM |
| Certification | ISO9000 ,ROHS,CE |
| Model Number | YG-PHN22-AU-M |
| Minimum Order Quantity | 1 |
| Price | Negotiate |
| Packaging Details | 10 pieces /carton box |
| Delivery Time | 3-5 days after despoit |
| Payment Terms | Western Union, MoneyGram, T/T, L/C |
| Supply Ability | 10000 pcs/ month |
Product Details
| Product Name | 1550nm Mini Optical Passive Node Built In WDM With SC Connector | RF Frequency Range | 40-1000MHz |
|---|---|---|---|
| Input Optical Power | 0~-10dBm | Output Port | 1 |
| Output Level | 68 DBuV | Wavelength | 1100~1600&1550nm |
| High Light | 1550nm WDM CATV Optical Node,68 dBuV CATV Optical Node,68 dBuV optical receiver node |
||
Product Description
1550nm Mini Optical Passive Node Built in WDM with SC Connector
1. PRODUCT DESCRIPTION
CATV converter for digital television, fiber to the home. This machine adopts the high sensitivity optical receiving tube, without power supply, no power consumption. When the input optical power output level Pin=-1dBm, Vo=68dBuV, economic, flexible application integration, application of fiber to the home network.
2. PRODUCT FEATURE
1.No Power required
2.Work bandwidth 45~1050MHz
3.Output Level=68dBμV (Pin=-1dBm)
3. MAIN APPLICATION
CATV FTTH
Integration of three networks
FTTH PON
Technique Parameter
| Optic feature | Unit | Index | Supplement | |
| Optical parameter | CATV work wavelength | nm | 1260~1620 | |
| 1540~1563 | ||||
| Pass wavelength | nm | 1310~1490 | ||
| Channel Isolation | dB | ≥40 | 1550nm&1490nm | |
| Response | A/W | ≥0.85 | 1310nm | |
| ≥0.9 | 1550nm | |||
| Receiving Power | dBm | +2~-14 | ||
| Optical return loss | dB | ≥55 | ||
| Optical fiber connector | SC/APC | |||
| RF parameter | Work bandwidth | MHz | 45~1050 | |
| Output level | dBμV | >68 | Digital TV (pin=-1dBm) | |
| Return loss | dB | ≥14 | 47~862MHz | |
| Output impedance | Ω | 75 | ||
| Output port number | 1 | |||
| RF tie-in | F-female | |||
| General feature | Work temp | ℃ | -20~+55 | |
| Storage temp | ℃ | -40~+85 | ||
| Work relative temp | ℃ | 5~95 |
