1550nm 862MHz CATV Optical Receiver With CWDM
| Place of Origin | Shanghai China |
|---|---|
| Brand Name | Yogel or OEM |
| Certification | ISO9000 ,ROHS,CE |
| Model Number | YG-AHN03-1F |
| Minimum Order Quantity | 1 |
| Price | Negotiate |
| Packaging Details | 1 piece/carton box |
| Delivery Time | 3-5 days after despoit |
| Payment Terms | Western Union, MoneyGram, T/T, L/C |
| Supply Ability | 10000 pcs/ month |
Product Details
| Product Name | 1550nm CATV Receiver Micro Fiber Optical Node Active FTTH Optical Receiver | CATV Working Wavelength | 1540~1560 |
|---|---|---|---|
| Pass Wavelength | 1310,1490 | AGC Control Range | 0~-9 |
| Output Level | >82dBUV | RF Output Level | ≥80 |
| High Light | 862MHz CATV optical receiver,862MHz optical receiver node,Yogel CATV optical receiver |
||
Product Description
1550nm CATV receiver micro fiber optical node Active FTTH Optical Receiver
1. Product Description
AGC Control range 1100 to 1600nm optical receiver WDM OR20 for Digital TV is home-based optical receiver catering to the ultimate goal of development of optical access and suitable for FTTH(fiber to the home) optical fiber network users access to the end. Analog or digital signal to home can be used together with the ONU or EOC achieving triple play.
2. Product feature
1. Low noise, high power, low power consumption and high cost performance
2. Excellent flatness in the bandwidth
3. Output attenuation control
4. With CWDM built-in, suitable for single fiber three wave system, RFTV working wavelength 1550nm and pass through wavelength 1310/1490nm. Can easily connect the ONU for EPON and GPON.
3. Technical Parameters
| Item | Unit | Paramter | Supplement |
| CATV working wavelength | 1540~1560 | ||
| Pass wavelength | nm | 1310,1490 | |
|
Receiving power |
(dBm) |
+2~-10 | Analog TV |
| +2~-18 | Digital TV | ||
| Return loss | (dB) | ≥45 | |
| Work bandwidth | MHz | 47~862/1000 | |
| Flatness | dB | ±0.75 | |
|
RF output level |
(dBuv) |
≥80 | Single output Pin:-9~0dBm |
| ≥76 | Dual outputs Pin:-9~0dBm | ||
| AGC control range | (dBm) | 0~-9 |
| AGC character | dB | ≤±0.5 | Pin:-9~+0dBm |
| Output level control | (dB) | 0-20 | MGC |
| Output return loss | (dB) | ≥14 | 47-862MHz |
| Output impedance | (Ω) | 75 | |
| Number of output port | ea | single output / dual outputs | |
| CNR | dB | ≥51 | Pin=-2dBm |
| CTB | dB | ≥61 | Pin=-2dBm |
| CSO | dB | ≥60 | Pin=-2dBm |
| Power supply | V | +8VDC | |
| Power consume | W | ≤3 | +8VDC,250mA |
| Work temperature | (℃) | -20~+60 | |
| Size | mm | 79*98*25.5 | (W)*(D)*(H) |
